Vacuum Controller  (VC100C)

Pdt. Code:VC100C

Measure Range 0-105.0kPa, Resolution 0.1kPa, Set Range 2~90kPa,  digital vacuum rate display.
PTFE electromagnetic valve & buffer bottle & filter bottle are equipped.






  • Pdt. Name/Model: Vacuum Controller(VC100C)
  • Pdt. Code: VC100C
  • Pdt. Features:

Vacuum Controller

Used for set, display and control vacuum rate in target system, esp. in processes of separating, condensing of low boiling temperature solution.

Solvent receiving rate raise to 99% even for low boiling temp. solvent.
- Built-in electromagnetic valve
- Equips in control power port for vacuum pump
- With buffer bottle and filter bottle for protection

VC100C Feature Curve Diagram:

SPECIFICATIONS

1 Measure Range 0.1-105KPa
2 Set Range 1-90KPa
3 Sensitivity 0.1KPa
4 Load Capacity 220V, 370W
5 Power 220V, 1P,50/60Hz
6 Dimensions (cm) 34x16x39H

CONFIGURATIONS

Symbol Instruction: / - None,  ● - Equipped,  ○ - Optional ( * - Only available when ordering of product, not for separate sale)

Note: Some specifications of relevant or customized models have some differences from that of standard model, for details, please consult with us.

  • Rotary Evaporator(R213B)

    Standard Configuration: 1L and 0.5L Evaporating Flask. Optional Capacity: 0.1~2L Evaporating Flask.
    Bath Temp.: 99°C digital display
    Features:
    - Economic model with diagonal water cooling and bath cap;
    - Easy flask taking-off design for both evaporating and receiving flask;
    - Can perform distilling & reflux.
    1L receiving flask with 35 spherical joint.  Diagonal condenser, Lifting Bath 99C.

  • Roator Evaporator(R214B)

    Standard Configuration: 1L and 0.5L Evaporating Flask. Optional Capacity: 0.1~2L Evaporating Flask.
    Bath Temp.: 99°C digital display
    Features:
    - Economic model with diagonal water cooling and bath cap;
    - Easy flask taking-off design for both evaporating and receiving flask;
    - Can perform distilling function.reflux is optional function.

    - 1L receiving flask with 35 spherical joint.  Vertical condenser, Manual lifting Bath 99°C. Ultimate vacuum 133Pa (1 torr) with durable sealing performance.  Rotation 10-180rpm.

  • Rotary Evaporator(R205B)

    Standard Configuration: 1L and 0.5L Evaporating Flask. Optional Capacity: 0.1~2L Evaporating Flask.
    Bath Temp.: 99°C digital display
    Features:
    - Economic model with diagonal water cooling and bath cap;
    - Easy flask taking-off design for both evaporating and receiving flask;
    - Can perform distilling ; reflux is optional device;
    - PTFE bottom discharge vavle.

  • Rotary Evaporator(R206B)

    Standard Configuration: 1L and 0.5L Evaporating Flask. Optional Capacity: 0.1~2L Evaporating Flask.
    Bath Temp.: 99°C digital display
    Features:

    - Equipped with vacuum gauge, digital display of bath temp. and rotation speed, bath cap;

    - 1L receiving flask with S35 spherical joint.  Vertical condenser, Manual lifting bath 99°C with +/-0.2°C intelligent temp. control.  Ultimate vacuum 133Pa (1 torr) with durable sealing performance. Digital rotation display.  Rotation speed 4-200rpm. Vacuum release valve and Vacuum meter are equipped.

  • Rotary Evaporator(R206D)

    Standard Configuration: 1L and 0.5L Evaporating Flask. Optional Capacity: 0.1~2L Evaporating Flask.
    Bath Temp.: 180°C digital display
    Features:

    - Equipped with vacuum gauge, digital display of bath temp. and rotation speed, bath cap;

    - 1L receiving flask with S35 spherical joint.  Vertical condenser, Manual lifting bath 180°C with +/-0.2°C intelligent temp. control.  Ultimate vacuum 133Pa (1 torr) with durable sealing performance. Digital rotation display.  Rotation speed 4-200rpm. Vacuum release valve and Vacuum meter are equipped;

    - Can not be equipped with pot lid.

  • Rotary Evaporator(R308B)

    3L evaporating flask ( Flange neck F50) , 2L receiving flask (S35 spherical joint )
    Sealing performance good.  Lifting bath 99℃ with ± 0.2℃ intelligent temp. control.  Digital rotation display 4rpm~180rpm. Vacuum meter equipped. Low operation noise.
    Optional part: 1. F50-->29 transitional join. 2. 0.1~2L evaporator flask.

  • Rotary Evaporator(R308D)

    3L evaporating flask.  2L receiving flask with ball joint.  Lifting bath 180°C with +/-0.2C intelligent temp. control.  Digital rotation display.  Rotation speed 4-180rpm. Vacuum meter equipped.

    Optional part : F50-->29 transitional joint available for choose.

  • Rotary Evaporator(R502B)

    5L·evaporating flask, 3L receiving flask with PTFE discharging valve.  Manual lifting bath, 99°C with +/-0.2°C intelligent temp. control. Ultimate vacuum 133Pa (1 torr) with durable sealing performance.  Digital rotation display.  Rotation speed 2-90rpm.  Strengthen motor head to perform heavy load.  Vacuum meter equipped.

    Optional part: 0.1~3L evaporating flasks.

  • Rotary Evaporator(R502D)

    5L·evaporating flask, 3L receiving flask with PTFE discharging valve.  Manual lifting bath, 180°C with +/-0.2C intelligent temp. control. Ultimate vacuum 133Pa (1 torr) with durable sealing performance.  Digital rotation display.  Rotation speed 2-90rpm.  Strengthen motor head to perform heavy load.  Vacuum meter equipped.



    Optional part: 0.1~3L evaporating flask.



  • Rotary Evaporator(R503B)

    5L evaporating flask, 3L receiving flask with PTFE discharging valve.  Manual lifting bath, 99°C with +/-0.2°C intelligent temp. control. Ultimate vacuum 133Pa (1 torr) with durable sealing performance.  Digital rotation display.  Rotation speed 2-90rpm.  Strengthen motor head to perform heavy load.  Vacuum meter, Vapor temperature thermometer & Reflux cork equipped.

    Optional part: 0.1~3L evaporating flasks.

  • Rotary Evaporator(R503D)

    5L·evaporating flask, 3L receiving flask with PTFE discharging valve.  Manual lifting bath, 180°C with +/-0.2C intelligent temp. control. Ultimate vacuum 133Pa (1 torr) with durable sealing performance.  Digital rotation display.  Rotation speed 2-90rpm.  Strengthen motor head to perform heavy load.  Vacuum meter, Vapor temperature thermometer & Reflux cork equipped.

    Optional part: 0.1~3L evaporating flask.

  • Rotary Evaporator(R1002B)

    10L Rotary Evaporator  with 10L/F95 evaporating flask, 5L receiving flask with PTFE discharging valve.



    Manal lifting bath, 3kw, 99℃ with +/-0.2℃ intelligent temp. control.  Ultimate vacuum 133Pa (1 torr) with durable sealing performance.



    Digital rotation display.  Frequency conversion rotation, speed 3-110rpm.  Vacuum meter equipped.

  • Rotary Evaporator(R1002D)

    10L Rotary Evaporator with 10L/F95 evaporating flask, 5L receiving flask with PTFE discharging valve.



    Manal lifting bath, 3kw, 180℃ with +/-0.2C intelligent temp. control.  Ultimate vacuum 133Pa (1 torr) with durable sealing performance.



    Digital rotation display.  Frequency conversion rotation, speed 3-110rpm.  Vacuum meter equipped.

  • Rotary Evaporator(R2002B)

    20L Rotary Evaporator with 20L/F95 evaporating flask, 10L receiving flask with PTFE discharging valve.



    Lifting bath, 5kw, 99℃ with +/-0.2℃ intelligent temp. control.  Digital rotation display.  Ultimate vacuum 133Pa (1 torr) with durable sealing performance.



    Frequency conversion rotation, speed 3-110rpm.  Vacuum meter equipped.

  • Rotary Evaporator(R2002D)

    20L Rotary Evaporator with 20L/F95 evaporating flask, 10L receiving flask with PTFE discharging valve.



    Lifting bath, 5kw, 180℃ with +/-0.2°C intelligent temp. control.  Digital rotation display.  Ultimate vacuum 133Pa (1 torr) with durable sealing performance.



    Frequency conversion rotation, speed 3-110rpm.  Vacuum meter equipped.

  • Rotary Evaporator(R2005KB)

    20L Rotary Evaporator with complete flange joint, no glass seizure risk. 20L/F120 evaporating flask, 10L receiving flask.



    PTFE charging &  discharging valve, Patent technology on tandem type continuous receiving.  Manual lifting bath, 5kw, 99℃ with +/-0.2℃ intelligent temp. control.  Ultimate vacuum 133Pa (1 torr) with durable sealing performance.



    Digital rotation display.  Frequency conversion rotation, speed 3-110rpm.  Vacuum meter and vapor temperature measure port equipped.

  • Rotary Evaporator(R2005KD)

    20L Rotary Evaporator with complete flange joint, no glass seizure risk. 20L/F120 evaporating flask, 10L receiving flask.  PTFE charging &  discharging valve,



    Patent technology on tandem type continuous receiving.  Manual lifting bath, 5kw, 180℃ with +/-0.2C intelligent temp. control.



    Ultimate vacuum 133Pa (1 torr) with durable sealing performance.  Digital rotation display.  Frequency conversion rotation, speed 3-110rpm.  Vacuum meter and vapor temperature measure port equipped.

  • Rotary Evaporator(R2006KB)

    Illustrations are for reference only.
    20L Rotary Evaporator with complete flange joint, no glass seizure risk.  SUS frame
    20L/F120 evaporating flask, 10L receiving flask.  PTFE charging &  discharging valve, Patent technology on tandem type continuous receiving.
    Electric Lifting bath, 5kw, 99℃ with +/-0.2℃ intelligent temp. control.  Digital rotation display.  Frequency conversion rotation, speed 3-110rpm.  Vacuum meter and vapor temperature measure port equipped.

  • Rotary Evaporator(R2006KD)

    20L Rotary Evaporator with complete flange joint, no glass seizure risk.  SUS frame
    20L/F120 evaporating flask, 10L receiving flask.  PTFE charging &  discharging valve, Patent technology on tandem type continuous receiving.
    Electric Lifting bath, 5kw, 180℃ with +/-0.2℃ intelligent temp. control.  Digital rotation display.  Frequency conversion rotation, speed 3-110rpm.  Vacuum meter and vapor temperature measure port equipped.

  • Rotary Evaporator(R5005KB)

    Illustrations are for reference only.
    50L Rotary Evaporator with complete flange joint, no glass seizure risk.
    50L/F120 evaporating flask, 20L receiving flask.  PTFE charging & discharging valve.  Patent technology on tandem type continuous receiving.  Lifting bath, 9kw, 99℃ with +/-0.2℃ intelligent temp. control.
    Ultimate vacuum 133Pa (1 torr) with durable sealing performance.   Digital rotation display.  Frequency conversion rotation, speed 3-110rpm.  Vacuum meter and vapor temperature measure port equipped. 380V 3-phase power supply.

  • Rotary Evaporator(R5005KD)

    50L Rotary Evaporator with complete flange joint, no glass seizure risk.
    50L/F120 evaporating flask, 20L receiving flask.  PTFE charging & discharging valve.  Patent technology on tandem type continuous receiving.  Lifting bath, 9kw, 180°C with +/-0.2C intelligent temp. control. Ultimate vacuum 133Pa (1 torr) with durable sealing performance.
    Digital rotation display.  Frequency conversion rotation, speed 3-110rpm.  Vacuum meter and vapor temperature measure port equipped. 380V 3-phase power supply.

  • Rotary Evaporator(R5006KB)

    50L Rotary Evaporator with complete flange joint, no glass seizure risk.  SUS frame
    50L/F120 evaporating flask, 20L receiving flask.  PTFE charging &  discharging valve, Patent technology on tandem type continuous receiving. Electric Lifting bath, 9kw, 99℃ with +/-0.2℃ intelligent temp. control.  Ultimate vacuum 133Pa (1 torr) with durable sealing performance.
    Digital rotation display.  Frequency conversion rotation, speed 3-110rpm.  vapor temperature measure port equipped. 380V 3-phase power supply.

  • Rotary Evaporator(R5006KD)

    50L Rotary Evaporator with complete flange joint, no glass seizure risk.  SUS frame
    50L/F120 evaporating flask, 20L receiving flask.  PTFE charging &  discharging valve, Patent technology on tandem type continuous receiving. Electric Lifting bath, 9kw, 180℃ with +/-0.2℃ intelligent temp. control.  Ultimate vacuum 133Pa (1 torr) with durable sealing performance.
    Digital rotation display.  Frequency conversion rotation, speed 3-110rpm.  vapor temperature measure port equipped. 380V 3-phase power supply.

  • Rotary Evaporator(R2005K2B)

    20L Rotary Evaporator with complete flange joint and bumping tube to protect reactant pumping into recieving flask, no glass seizure risk. 20L/F120 evaporating flask, 10L receiving flask.



    PTFE charging &  discharging valve, Patent technology on tandem type continuous receiving.  Manual lifting bath, 5kw, 99℃ with +/-0.2℃ intelligent temp. control.  Ultimate vacuum 133Pa (1 torr) with durable sealing performance.



    Digital rotation display.  Frequency conversion rotation, speed 3-110rpm.  Vacuum meter and vapor temperature measure port equipped.

  • Rotary Evaporator(R2005K2D)

    20L Rotary Evaporator with complete flange joint and bumping tube to protect reactant bumping into recieving flask, no glass seizure risk. 20L/F120 evaporating flask, 10L receiving flask.



    PTFE charging &  discharging valve, Patent technology on tandem type continuous receiving.  Manual lifting bath, 5kw, 180℃ with +/-0.2℃ intelligent temp. control.  Ultimate vacuum 133Pa (1 torr) with durable sealing performance.



    Digital rotation display.  Frequency conversion rotation, speed 3-110rpm.  Vacuum meter and vapor temperature measure port equipped.

  • Rotary Evaporator(R2006K2B)

    Illustrations are for reference only.
    20L Rotary Evaporator with complete flange joint and pumping tube to protect reactant pumping into recieving flask, no glass seizure risk.  SUS frame
    20L/F120 evaporating flask, 10L receiving flask.  PTFE charging &  discharging valve, Patent technology on tandem type continuous receiving.
    Electric Lifting bath, 5kw, 99℃ with +/-0.2℃ intelligent temp. control.  Digital rotation display.  Frequency conversion rotation, speed 3-110rpm.  Vacuum meter and vapor temperature measure port equipped.

  • Rotary Evaporator(R2006K2D)

    Illustrations are for reference only.
    20L Rotary Evaporator  with complete flange joint, no glass seizure risk.  Bumping tube equipped. SUS frame.
    20L/F120 evaporating flask, 10L receiving flask. PTFE charging &  discharging valve, Patent technology on tandem type continuous receiving.
    Electric Lifting bath, 5kw, 180°C with +/-0.2°C intelligent temp. control. Digital rotation display. Frequency conversion rotation, speed 3-110rpm. Vacuum meter and vapor temperature measure port equipped.

  • Rotary Evaporator(R5005K2B)

    50L Rotary Evaporator with complete flange joint and pumping tube to protect reactant bumping into recieving flask, no glass seizure risk.
    50L/F120 evaporating flask, 20L receiving flask.  PTFE charging & discharging valve.  Patent technology on tandem type continuous receiving.  Lifting bath, 9kw, 99℃ with +/-0.2℃ intelligent temp. control. Ultimate vacuum 133Pa (1 torr) with durable sealing performance.
    Digital rotation display.  Frequency conversion rotation, speed 3-110rpm.  Vacuum meter and vapor temperature measure port equipped. 380V 3-phase power supply.

  • Rotary Evaporator(R5005K2D)

    50L Rotary Evaporator with complete flange joint, no glass seizure risk. Bumping tube equipped.  SUS frame.
    50L/F120 evaporating flask, 20L receiving flask.  PTFE charging &  discharging valve, Patent technology on tandem type continuous receiving.
    Electric Lifting bath, 9kw, 180°C with +/-0.2°C intelligent temp. control.  Ultimate vacuum 133Pa (1 torr) with durable sealing performance.  Digital rotation display.  Frequency conversion rotation, speed 3-110rpm.  vapor temperature measure port equipped. 380V 3-phase power supply.

  • Rotary Evaporator(R5006K2B)

    Illustrations are for reference only.
    50L Rotary Evaportor with complete flange joint and bumping tube to protect reactant pumping into recieving flask, no glass seizure risk.  SUS frame
    50L/F120 evaporating flask, 20L receiving flask.  PTFE charging &  discharging valve, Patent technology on tandem type continuous receiving. Electric Lifting bath, 9kw, 99℃ with +/-0.2℃ intelligent temp. control.  Ultimate vacuum 133Pa (1 torr) with durable sealing performance.
    Digital rotation display.  Frequency conversion rotation, speed 3-110rpm.  vapor temperature measure port equipped. 380V 3-phase power supply.

  • Rotary Evaporator(R5006K2D)

    Illustrations are for reference only.
    50L Rotary Evaporator with complete flange joint, no glass seizure risk.  Bumping tube equipped(It can prevent the material from boiling up and contaminate the collected material when it enters the bottle
    SUS frame.50L/F120 evaporating flask, 20L receiving flask.  PTFE charging &  discharging valve, Patent technology on tandem type continuous receiving.
    Electric Lifting bath, 9kw, 180°C with +/-0.2°C intelligent temp. control.  Ultimate vacuum 133Pa (1 torr) with durable sealing performance.  Digital rotation display.  Frequency conversion rotation, speed 3-110rpm.  vapor temperature measure port equipped. 380V 3-phase power supply.

  • Multifunctional Reactor(FH201)

    2L, 5-neck vacuum reaction flask.  Bath 180℃ with +/-0.2℃ intelligent temp. control.  Accessories for Reflux, Drip, Temperature measure and Charging included.

  • Multifunctional Reactor(FH501)

    5L, 5-neck vacuum reaction flask. Frequency conversional stir. Bath 180℃ with +/-0.2℃ intelligent temp. control.  Accessories for Reflux, Drip, Temperature measure and Charging inluded.

  • Multifunctional Reactor(FH2006)

    20L, 7+1 neck vacuum reaction flask, complete flange neck w/no glass seizure risk, PTFE valves, PTFE non-dead-angle bottom discharge valve,



    Frequency conversion stir with patent  inclined stereo-flow stir, Adiabatic Bath 180°C with +/-0.2°C intelligent temp. control.



    Dripping flask, Wheels, Dry heating protection device. Various optional functions and accessories available. SUS stand

  • Multifunctional Reactor(FH5006)

    50L, 7+1 neck vacuum reaction flask, complete flange neck w/no glass seizure risk, PTFE valves, PTFE non-dead-angle flush type bottom discharge valve (side discharge type optional at request), Frequency conversion stir with patent inclined stereo-flow stir design,
    Adiabatic Bath 180°C with +/-0.2°C intelligent temp. control, 4kW heating power. With dry heating protection.With very good and durable sealing performance.
    Various optional functions and accessories available. SUS304 stand  220V, 50/60Hz

  • Cap Style Jacketed Reactor (FC1003)

    10L, 6+1 jacketed reaction flask,complete flange neck w/no glass seizure risk.
    PTFE charging valve, non-dead-angle discharge valve with Ø20 drain hole, Tangent style flange jacket inlet/outlet,
    Power frequency conversion stir, Drip, Reflux, Digital Thermometer included. Long duration seal performance. SUS stand

  • Cap Style Jacketed Reactor (FC2003)

    Illustrations are for reference only.

    20L, 6+1 jacketed reaction flask, complete flange neck w/no glass seizure risk.  PTFE charging valve, non-dead-angle discharge valve with Ø20 drain hole,
    Tangent style flange jacket inlet/outlet with glass port protection design Power Frequency conversion stir, Drip, Reflux, Digital Thermometer included.
    Long duration sealing parts (all Oring are chemical resistant)SUS frame, seat stand style which is convenient for reaction flask loading.

  • Cap Style Jacketed Reactor (FC3003)

    30L, 7+1 jacketed reaction flask, complete flange neck w/no glass seizure risk.  PTFE charging valve, non-dead-angle pre-load side discharge valve with Ø20 drain hole,
    Tangent style flange jacket inlet/outlet, Power Frequency conversion stir, Drip, Reflux, Digital Thermometer included.Long duration sealing parts (all Oring are chemical resistant)
    SUS frame, seat stand style

  • Cap Style Jacketed Reactor (FC5003)

    50L, 7+1  jacketed reaction flask,complete flange neck w/no glass seizure risk.  PTFE charging valve, non-dead-angle pre-loade side discharge valve with Ø32 drain hole,
    Tangent style flange jacket inlet/outlet, Frequency conversion power stir (gear down), 5L Drip, Reflux, Digital Thermometer included.
    All joints are flange joint equipped with easy-clip flange press ring.

  • Cap Style Jacketed Reactor (FC10003)

    100L, 7+1  jacketed reaction flask, complete flange neck w/no glass seizure risk.  PTFE charging valve, non-dead-angle pre-loade side discharge valve with Ø32 drain hole,
    Tangent style flange jacket inlet/outlet,  Frequency conversion power stir (gear down), 5L Drip, Reflux, Digital Thermometer included.
    All joints are flange joint equipped with easy-clip flange press ring. In-built with jacket pressure release device (safety device).

  • Cap Style Jacketed Reactor (FC15003)

    Illustrations are for reference only.


    150L, 7+1  jacketed reaction flask, complete flange neck w/no glass seizure risk.



    PTFE charging valve, non-dead-angle discharge valve, Tangent style flange jacket inlet/outlet, Frequency conversion power stir, 5L Drip, Reflux, Digital Thermometer included.



    All joints are flange joint equipped with easy-clip flange press ring.

  • Cap Style Jacketed Reactor (FC0202)

    250ml, 5+1 neck jacketed reaction flask with non-dead-angle discharge valve, Tangent style flange jacket inlet/outlet, Drip, Reflux, Thermometer and Charging accessories included.

  • Cap Style Jacketed Reactor (FC0502)

    500ml, 5+1 neck jacketed reaction flask with non-dead-angle discharge valve, Tangent style flange jacket inlet/outlet, Drip, Reflux, Thermometer and Charging accessories included.

  • Cap Style Jacketed Reactor (FC102)

    1000ml, 5+1 neck jacketed reaction flask with non-dead-angle discharge valve, Tangent style flange jacket inlet/outlet, Drip, Reflux, Thermometer and Charging accessories included.

  • Cap Style Jacketed Reactor (FC202)

    2000ml, 5 neck reaction head, downward open jacketed reaction body with non-dead-angle discharge valve.  Tangent style flange jacked inlet/outlet, glass accessories included.  Can attach different capacity flask under same reaction head.

  • Cap Style Jacketed Reactor (FC302)

    Illustrations are for reference only.

    3L, 5 neck reaction head,
    downward open jacketed reaction body with non-dead-angle discharge valve.
    Tangent style flange jacked inlet/outlet,
    glass accessories included.
    Can attach different capacity flask under same reaction head.

  • Water Circulation Vacuum Pump(SHB-3)

    2.6kPa, 2×10L/min, vacuum pressure adjustable, sus pump head, resist certain corrosion (fit for 1L-10L equipments)

  • Vane pump(2XZ-2)

    6.7×10-2Pa ,120L/min.   Not for pump steam or corrosive gas. Product dealt by SENCO

  • Chemical Diaphragm Pump(101Z)

    800Pa·16L/min·, with gas ballast valve,  Anti-corrosive.  Product dealt by SENCO.

  • Chemical Diaphragm Pump(MZ 2C)

    700Pa·38L/min, with gas ballast valve,  Anti-corrosive.  Product dealt by SENCO.

  • Chemical Diaphragm Pump(301z)

    Anti-corrosion chemical diaphragm pump.

    800Pa·38L/min·German Brand·Dealt by Senco

  • Chemical Diaphragm Pump(ME 4C)

    7kPa (70mbar / 52Torr), 65L/min, with gas ballast valve,  Anti-corrosive.  Product dealt by SENCO.

  • Chemical Diaphragm Pump(601e)

    7.5Kpa (75mbar), 63L/min, Anti-corrosive.   Product dealt by SENCO.

  • Promotion:
